橡胶接头漏水是什么原因导致的?

时间: 2019-03-19 17:10 浏览次数:
橡胶接头漏水是什么原因导致的?

What causes the rubber joint to leak?
橡胶接头漏水是什么原因导致的?
   橡胶接头漏水的最大的原因应该是由于安装不准确。近一些客户反应橡胶接头产品在安装和试运行会有漏水现象,出厂前都是通过压力测试和严密封闭性实验测试,符合标准后才会销售到客户手中。上海松夏减震器有限公司的技术担担任职务务的人觉得安装运用有误,可曲挠橡胶接头在法兰联接过程中利用可曲挠橡胶接头自身橡胶端面的突出橡胶边缘作为严密封闭材料来严密封闭橡胶软接头法兰端面,所以一样在扣槽橡胶软接头容易发生漏水现象,端面全严密封闭橡胶软接头不会有这种现象,主要原因是扣槽橡胶接头安装时刻没有很好的将橡胶严密封闭端面很好的卡进法兰的凹槽中,这样橡可曲挠橡胶接头在运用过程中容易发生部分压力集中在边缘处显露出来泄露。在可曲挠橡胶接头安装过程中必须使橡胶边沿卡扣到到法兰槽里,所以安装后反法兰可以很严密封闭的卡住橡胶端好,运用中不会出现渗漏现象。当有部分的安装工作,螺钉不泄露,这是不准确的严密封闭面泄露后,拧紧螺钉将粉碎橡胶边缘,使严密封闭面损伤,橡胶球的表面的一小批遭到破坏。这种方法是不准确的,我厂泄露,该橡胶软接头卸下被还原,之后调整装置。

The biggest cause of rubber joint leakage should be due to inaccurate installation.Recently, some customers reported that there would be water leakage in the installation and trial operation of rubber joint products. Before leaving the factory, they all passed the pressure test and tight sealing test, and were sold to customers after meeting the standards.Pine xia shock absorber co., LTD. Shanghai technical bear positions of people think that using the wrong installation, in a flexible rubber joint used in the process of flange connection in a flexible rubber joint of rubber face own outstanding rubber edge to tightly closed as tightly closed material rubber soft joint flange end face, so the same accounting groove soft rubber joints are prone to leakage phenomenon, face all tightly closed soft rubber joints will not have this kind of phenomenon, the main reason is that buckle slot will be a very good rubber joint installation moments don't have rubber tightly closed end face good card into the groove of the flange,This flexible rubber joints in the use of the process is prone to part of the pressure concentrated on the edge of the exposed leak.In the installation process of flexible rubber joint, it is necessary to make the rubber edge buckle into the flange slot, so the anti-flange can be very close to the stuck rubber end after installation, there will be no leakage in use.When there is part of the installation work, the screw does not leak, which is inaccurate tight sealing surface leakage, tighten the screw will crush the rubber edge, so that the tight sealing surface damage, rubber ball surface of a small batch of damage.This method is not accurate, I plant leakage, the rubber soft joint was removed after the reduction of the adjustment device.
